Alkatronik Profibus Bus Connector 6es7 972-0bb41-0xa0

Profibus Bus Connector 6ES7 972-0BB41-0XA0

Descriptions:

This Profibus Bus Connector features ROFIBUS35 °, built-in terminal lead resistance, no programming interface, terminal connector, transmission rate up to 12 Mbit/S. With a built-in terminal matching resistor. and convenient to use, connect the bus cable directly to the DP bus connector and insert the connector socket into the Profibus master/slave interface.

Features:

• ROFIBUS35 ° built-in terminal lead resistance, no programming interface, terminal connector.
• DP bus connector is the RS485 common interface parts between the PROFIBUS DP protocol master and the slave cable.
• Mainly used in manufacturing automation system unit level and the field level
• level of communication.
• Between the PLC communication port and Profibus cable, the data can be transmitted through a round-robin communication, transmitting the signal at a rate of 12 M bits.
• With a built-in terminal matching resistor.
• The design of the connector fully takes into account the Angle of cable inlet line and the problem of alleviating tension. The built-in grounding metal plate effectively prevents the common mode interference and has strong electromagnetic compatibility performance
• Convenient to use, connect the bus cable directly to the DP bus connector and insert the connector socket into the Profibus master/slave interface.

Specifications:

• Name: Profibus bus connector (DP head)
• Model: 972-0BB41-0XA0
• Transmitting rate :12 Mbit/s
• Weight:44g

Paket içeriği :

• 1 Adet 6ES7 972-0BB41-0XA0 Profibus Bus Connector
