Hikvision Hıkvısıon 4İn1 8Kanal 1080P Ds-7108Hghı-K1 1X 6Tb Ahd Kayıt Cihazı

8-ch 1080p H.265+ DVR 8 channels and 1 HDD mini size DVR
Efficient H.265 pro+ compression technology
Encoding ability up to 1080p @ 15 fps
5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
Up to 12 network cameras can be connected
Recording
Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding Resolution When 1080p Lite mode is not enabled: 4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF
When 1080p Lite mode is enabled: 4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF
Frame Rate Main stream: When 1080p Lite mode is not enabled: For 4 MP stream access: 4 MP lite@15fps
1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps For 1080p stream access: 1080p/720p@15fps
VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080p Lite mode is enabled: 4 MP lite/3 MP@15fps
1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) Sub-stream: WD1/4CIF@12fps
CIF@25fps (P)/30fps (N)
Video Bitrate32 Kbps to 6 Mbps
Dual-StreamSupport
Stream TypeVideo, Video & Audio
Audio CompressionG.711u
Audio Bitrate64 Kbps
Video And Audio
IP Video Input 2-ch (up to 10-ch) Enhanced IP mode on: 4-ch (up to 12-ch), each up to 4 Mbps Up to 6 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras
Incoming Bandwidth48 Mbps
Analog Video Input 8-ch BNC interface (1.0 Vp-p, 75 ?), supporting coaxitron connection
HDTVI Input 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60

*: The 3 MP signal input is only available for channel 1 of DS-7104HQHI-K1.
AHD Input4 MP, 1080p25, 1080p30, 720p25, 720p30
HDCVI Input4 MP, 1080p25, 1080p30, 720p25, 720p30
CVBS InputSupport
VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio Input 1-ch, RCA (2.0 Vp-p, 1 K?) 8-ch via coaxial cable
Audio Output1-ch, RCA (Linear, 1 K?)
Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 K?) (using the first audio input)
Synchronous Playback8-ch
Network
Total Bandwidth96 Mbps
Remote Connection64
Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, http, ONVIF
Network Interface1, RJ45 10M/100M self-adaptive Ethernet interface
Auxiliary Interface
SATA1 SATA interface
CapacityUp to 6 TB capacity for each disk
Alarm In/OutN/A
USB InterfaceReal panel: 2 × USB 2.0
General
Power Supply12 VDC, 1.33 A
Consumption? 12 W
Working Temperature-10 °C to +55 °C (+14 °F to +131 °F)
Working Humidity10% to 90%
Dimension (W × D × H)200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
? 1 kg (2.2 lb)
