Dahua IPC-HDW2449T-S-IL-0280B 4mp 2.8mm 30MT H.265 IP67 Poe Color-Vu Ir Dome Ip Kamera

DAHUA IPC-HDW2449T-S-IL-0280B 4MP 2.8MM 30MT H.265 IP67 POE COLOR-VU IR DOME IP KAMERA

Ürün özellikleri

Renk
Beyaz

Bağlantı Tipi
Kablosuz

Kamera Tipi
Dome Kamera

Çözünürlük
4 MP
ahua IPC-HDW2449T-S-IL-0280B 4mp 2.8mm Sabit Lens Full-Color Dahili Sesli H.265+ IP Dome Kamera 4MP Smart Dual Illumination Fixed-focal Eyeball WizSense Network Camera > 4 MP 1/2,9" CMOS görüntü sensörü, düşük parlaklık ve yüksek tanımlı görüntü. > Çıkışlar maks. 4 MP (2688 × 1520)@20 fps ve 2560 × 1440 @25/30 fps'yi destekler > H.265 codec bileşeni, yüksek sıkıştırma oranı, ultra düşük bit hızı. > Dahili sıcak ışık/IR LED, maks. aydınlatma mesafesi 30 m ve max. sıcak ışık mesafesi 30 m'dir. > ROI, SMART H.264+/H.265+, esnek kodlama, çeşitli bant genişliği ve depolama ortamlarına uygulanabilir. > Döndürme modu, WDR, 3D NR, HLC, BLC, dijital filigran, çeşitli izleme sahnelerine uygulanabilir. > Akıllı izleme: İzinsiz giriş, tripwire (iki işlev, araç ve insanın sınıflandırılmasını ve doğru tespitini destekler). > Maks. 256 G Mikro SD kart; MIC'de yerleşik. > 12 VDC/PoE güç kaynağı, kurulumu kolaydır. > IP67 koruması. > SMD + Camera Image Sensor 1/2.9" CMOS Max. Resolution 2688 (H) × 1520 (V) ROM 128 MB RAM 128 MB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.006 lux@F1.6 (Color, 30 IRE) 0.0006 lux@F1.6 (B/W, 30 IRE) 0 lux (Illuminator on) S/N Ratio >56 dB Illumination Distance up to 30 m (98.43 ft) (IR); up to 30 m (98.43 ft) (Warm light) Illuminator On/Off Control Auto; Manual Illuminator Number 1 (IR LED); 1 (Warm light) Pan/Tilt/Rotation Range Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° Lens Lens Type Fixed-focal Lens Mount M12 Focal Length 2.8 mm Max. Aperture F1.6 Field of View 2.8 mm: H: 95°; V: 52°; D: 114° Iris Control Fixed Close Focus Distance 2.8 mm: 0.9 m (2.95 ft); DORI Distance Lens Detect Observe Recognize Identify 2.8 mm 63.6 m (208.66 ft) 25.4 m (83.33 ft) 12.7 m (41.67 ft) 6.4 m (20.99 ft) Intelligence IVS (Perimeter Protection) Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) Smart Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos Video Video Compression H.264H; H.265; H.264; H.264B; MJPEG (Only supported by the sub stream) Smart Codec Smart H.265+; Smart H.264+ Video Frame Rate Main stream: 2688 × 1520@(1–20 fps)/2560 × 1440@(1–25/30 fps) Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Stream Capability 2 streams Resolution 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Bit Rate Control CBR/VBR Video Bit Rate H.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbps Day/Night Auto(ICR)/Color/B/W BLC Yes HLC Yes WDR 120 dB White Balance Auto; natural; street lamp; outdoor; manual; regional custom Gain Control Auto;Manual Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Region of Interest (RoI) Yes (4 areas) Image Rotation 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) Mirror Yes Privacy Masking 4 areas Audio Built-in MIC Yes Audio Compression G.711a; G.711Mu; PCM; G.726 Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; SMD; voltage detection; security exception Network Network Port RJ-45 (10/100 Base-T) SDK and API Yes Network Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP Interoperability ONVIF (Profile S/Profile T); CGI; P2P; Milestone User/Host 6 (Total bandwidth: 36 M) Storage FTP; SFTP; Micro SD card (support max. 256 GB) Browser IE; Chrome; Firefox Management Software DSS; DMSS Mobile Client iOS; Android Cyber Security Configuration encryption; Trusted execution; Digest; Security logs; WSSE; Account lockout;syslog; Video encryption; 802.1x; IP/MAC filtering; HTTPS; Trusted upgrade; Trusted boot; Generation and importing of X.509 certification Certification Certifications CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 Power Power Supply 12 VDC/PoE (802.3af) Power Consumption Basic: 2.1 W (12 VDC); 2.5 W (PoE) Max. (H.265 + intelligence + WDR + warm light): 4.4 W (12 VDC); 5.2 W (PoE) Environment Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F) Operating Humidity ≤95% Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F) Protection IP67 Structure Casing Material Inner core: Metal ; Cover: Plastic Product Dimensions 100.9 mm × Φ109.9 mm (3.97" × Φ4.33") Net Weight 0.37 kg (0.82 lb) Gross Weight 0.51 kg (1.12 lb)
