JBL 305P Mkıı 5 Inç Referans Monitörü

Jbl 305P MKII 5 inç 82 Watt Aktif Referans Monitörü (TEK)

Patented Image Control Waveguide for detailed imaging and a broad, room-friendly sweet spot

Next-generation JBL transducers for optimized transient response and improved linearity

Patented Slip Stream™ low-frequency port for superior bass performance at all playback levels

Dual integrated, custom Class-D amplifiers provide 82 watts of power for high output and dynamic range

New Boundary EQ settings compensate for low frequency variants introduced by the environment

HF Trim switch adjusts high-frequency output to room acoustics or personal preferences

Flexible connectivity with balanced XLR and 1/4" TRS inputs, +4dBu / -10dBV input-sensitivity switch and adjustable volume control

Engineered to JBL Linear Spatial Reference design criteria for outstanding accuracy in any working space

Strenuous JBL 100-hour full-power test ensures years of reliability

Sleek, modern design provides a visual upgrade to any studio

• LF DRIVER SIZE203mm (5")
• HF DRIVER SIZE25mm (1")
• HF DRIVER TYPESoft dome
• CROSSOVER1725Hz 4th order acoustic Linkwitz-Riley
• OK FOR USE NEAR MAGNETICALLY SENSITIVE EQUIPMENTYes
• INPUT SENSITIVITY (-10dBV INPUT)92dB / 1m
• POWER CONFIGURATIONBi-amplified
• HF DRIVER POWER AMP41W, Class-D
• LF DRIVER POWER AMP41W, Class-D
• FREQUENCY RESPONSE (±3dB)49Hz – 20kHz
• FREQUENCY RANGE (-10dB)43Hz – 24kHz
• LOW FREQUENCY EXTENSION (-10dB)43Hz
• MAXIMUM CONTINUOUS SPL94dB
• MAXIMUM PEAK SPL108dB
• MAXIMUM PEAK INPUT LEVEL (-10dBV / +4dBu)+6dBV / +20.3dBu
• SYSTEM DISTORTION CRITERIA
